Medical sterile tray and blister heat sealing machine JL-5600/6000
Introduction
Medical sterile tray and blister heat sealing machineApplicable blister and dialysis paper as below:
1. Medical PVC blister clam shell
2. PET white blister clam shell
3. APET white blister clam shell
4. PETG blue-ray blister clam shell6763 Eastman
5. Dialysis paper, bacteria resistance, tear strength, 1073B, 1059B, etc coating paper
| Model | JL-5600W/A | JL-5600W/B | JL-6000W/A | JL-6000W/B |
| Power | 5600W/A | 5600W/B | 6000W/A | 6000W/B |
| Air pressure | 8KG or more | 8KG or more | 8KG or more | 8KG or more |
| Voltage | 380V 3phase5wires | 380V 3phase5wires | 380V 3phase5wires | 380V 3phase5wires |
| Heating plate size | 300*700MM | 350*700M | 300*840MM | 350*800MM |
| Effective welding size | 220*620MM | 270*620MM | 220*760MM | 270*720MM |
| Max welding size | 250*650MM | 300*650MM | 250*790MM | 300*750MM |
| Machine dimension | 860*880*1600MM | 860*940*1600MM | 860*1020*1600MM | 966*935*1600MM |
